Battery Test Solution

Battery Test System

Battery Test System:

Constantly innovating in a robust R&D environment, Chroma has a range of Battery test equipment solutions. It has pioneered Battery Test System, providing solutions at Cell, Module and Pack levels.

At the cell level, Chroma helps to test various parameters, from pre-charging to leakage current, for both linear circuits and regenerative AC/DC, ensuring defect-free electrolyte injection. 

At the module and pack levels, Chroma helps to test cell sorting and module assembly. Battery Management System (BMS) Printed Circuit Board Analysis (PCBA) and End-of-Line (EOL) tests, function tests, simulated test beds and test software platforms make Chroma a complete solution provider.

With the automotive industry moving swiftly into a new era of advanced EV technology, innovative new solution ‘ Battery Test System’  for accurate testing of Batteries, AC/DC charges, power components, and in-vehicle electronics are an absolute necessity.  Having  a strong Battery Test System solution in place enhances the efficiency of vehicle and guarantees safety.

MELSS provides high-end Battery Test Systems from Chroma for a diverse list of electric vehicle industry players across the board.  Our range of testing solutions is tailored to meet a variety of battery requirements, enabling thorough testing of cells, modules, and packs of various sizes.

Battery Test system from Chroma is one of the many Engineering and Technology solutions brought to you by MELSS. For more: https://go.melss.com/1b8

Click here to learn on other Test System

Watch Video on Battery Test System

Battery Test System –  Battery Cell Test solution

Battery Test System

Battery Cell Charge/Discharge Test System

Model 17011

  • High precision output and measurement up to 0.015% of full scale
  • Fast current response up to <100 μS
  • High sampling rate up to 10 mS
Learn More
Battery Test System

Battery Cell Formation System

Model 17000 series

  • Saving Charging Power (BVT/Switching)
  • Energy Recycle (ERM/Switching)
  • N+1 Redundant DC Power
Learn More

Cell Insulation Test

Battery Test System

Battery Cell Insulation Tester

Model 11210

  • Test voltage: up to 1KV(dc)
  • Charge current: 50mA max.
  • Wide range of Leakage Current (LC) measurement (10pA ~ 20mA)
  • Automatic test with sequence: charge-dwell-measure-discharge
Learn More
Battery Test System

Battery Cell Formation System

Model 17000 series

  • Max. output voltage: 6kV (Depends on DUT’s capacitance)
  • Pulse interval: 30ms ~ 3000ms
  • 8 types of judgments
Learn More

Battery Test System – Battery Pack/Module Test Solution

Battery Test System

Regenerative Battery Pack Test System

Model 17020

  • Voltage 20V/60V/100V/200V/500V for EV, storage battery pack/module test
  • Max 60 independant channels, parallel for high current
Learn More
Battery Test System

Regenerative Battery Pack Test System

Model 17020E

  • Charge/discharge modes (CC, CV, CP) Range: 10kW-20kW/60V-100V/ 180A-100A per channel (Up to 800A(Parallel))
  • Regenerative battery energy discharge, efficiency 85%
  • Driving cycle simulation
Learn More
Battery Test System

Regenerative Battery Pack Test System

Model 17020E

  • Voltage range：10~1200V
  • Power range：90~500kW
  • Dynamic charge/discharge test, driving cycle simulation
Learn More
Battery Test System

Regenerative Battery Pack Test System

Model 17040

  • Voltage range : 60~1000V, Current range : 0~750A, Power range : 0~300kW
  • Accuracy current / voltage measurement (±0.05%FS / ±0.02%FS)
  • Multiple voltage / current ranges for auto ranging function
Learn More
Battery Test System

16CH Battery Cell Simulator

Model 87001

  • Operating mode : CC/CP
  • Channel power: 25W, Channel voltage: 5V, Channel current: 5A (parallelable)
  • Bidirectional power supply design
  • 480-cell battery pack voltage simulation ability (connected in series)
Learn More
Battery Test System

Battery Simulator

Model A170202

  • Multi-channel battery packs simulation.
  • Follow the battery cell curve behavior to simulate battery state.
  • Able to set frequently used parameters for battery pack and rapidly customize initial output state.
Learn More

Battery Test System – Cell Voltage and Temperature Measurement

16CH Battery Cell Simulator Model 87001

16CH Battery Cell Simulator

Model 87001

  • Operating mode : CC/CP
  • Channel power: 25W, Channel voltage: 5V, Channel current: 5A (parallelable)
  • Bidirectional power supply design
  • 480-cell battery pack voltage simulation ability (connected in series)
Learn More
Thermal/Multi-Function Data Logger Model 51101 series

Thermal/Multi-Function Data Logger

Model 51101 series

  • 1000VDC channel to channel isolation
  • 0.5℃ accuracy and 0.01℃ resolution
Learn More

Battery Test System – Battery Pack Manufacture Test Solutions

Battery Test System - Regenerative Battery Pack Test System Model 17020

Regenerative Battery Pack Test System

Model 17020

  • BMS Function Test, Battery (failure) Simulator
  • It is for testing the function of battery pack in the production line.
  • Inspect battery module performance.
Learn More
Battery Pack Auto Test System Model 8700

Battery Pack Auto Test System

Model 8700

  • Specifically designed for battery production line, or battery development testing.
  • Increases QA efficiency by up to 80%
  • Inspection of BMS functions, connector withstand voltage, consistency, and performance of battery module.
Learn More
16CH Battery Cell Simulator Model 87001

16CH Battery Cell Simulator

Model 87001

  • Operating mode : CC/CP
  • Channel power: 25W, Channel voltage: 5V, Channel current: 5A (parallelable)
  • Bidirectional power supply design
  • 480-cell battery pack voltage simulation ability (connected in series)
Learn More
Regenerative Battery Pack Test System Model 17040

Regenerative Battery Pack Test System

Model 17040

  • NEW The latest 100V wide range of models (applicable to 40V/50V/60V/80V/100V models) 5kW/10kW/15kW/up to 1000V Easy Master/Slave Parallel & Series Operation up to 150kW
  • 5kW/10kW/15kW/up to 1000V
  • Easy Master/Slave Parallel & Series Operation up to 150kW
Learn More
DC Power Supply Model 62000P Series

DC Power Supply

Model 62000P Series

  • 600W / 1200W / 2400W / 5000W
  • Wide Range of Voltage & Current Combinations with Constant Power
  • Auto Sequencing Programming: 10 Programs / 100 Sequences / 8 bit TTL
  • Soft Panels for Instrument Control and
Learn More

Battery Test System – Battery Pack After Service Test System

Battery Test System - Battery Pack Balance ATS Model 8700

Battery Pack Balance ATS

Model 8700

  • Connecting 60 batteries in a series and up to 120 batteries are supported
  • DCIR test
  • Cell capacity test
Learn More

Battery Test System  – AOI System

Battery Test System - Cylindrical Battery Cell Automated Optical Inspection System Model 7505-K006

Cylindrical Battery Cell Automated Optical Inspection System

Model 7505-K006

  • Applies to various cylindrical battery sizes on the mainstream market
Learn More
Battery Test System - Thin Film Thickness Automated Optical Metrology System Model 7505-K007

Thin Film Thickness Automated Optical Metrology System

Model 7505-K007

  • Applies to Roll to Roll processing and thin film thickness inspection
Learn More
Battery Test System - Inline Printing Quality Automated Optical Inspection System Model 7505-K009

Inline Printing Quality Automated Optical Inspection System

Model 7505-K009

  • Applies to Roll to Roll processing and on-line quality control
Learn More
